Q4 Surface Mount Lights with DRL
Square Q4 surface mount lights with 4 Pcs 3W CREE or Osram LEDs and 4 Pcs 0.5W white LEDs for DRL. Compliant with ECE R65 and R10, SAE J595 class1.
- LED Power: 4pcs 3W LEDs and 4pcs 0.5W white LEDs
- Lens: Fresnel lens
- LED Lifespan: 100000H
- Flash Pattern: 19
- Input Voltage: DC 12-24V
- Max Power: 12W
- Average Current Draw: /
- Colour Available: single color
- Ambient Temperature: -30--+70℃
- Waterproof: IP67
- Product Dimension: 57 x 45 x 11mm
- Mounting: Surface mount or 3M mount
- Certifications: ECE R65, R10 and SAE
- Wire: 5 wires
- Cable Length: 20cm
- Material: UV-resistant PC lens and PP material
- Net Weight: 30g
Features:
4 Pcs 3W CREE or Osram LEDs and 4 Pcs 0.5W white LEDs for DRL
Compliant with ECE R65 and R10, SAE J595 class 1.
Powered by DC 12 -24V
Single color available
Surface mount or 3M mount for optional choice
New design program and easy to sync and alternate lights together
Built-in 19 selectable flash patterns
Pattern Memory available
IP-67 Standard, Weatherproof
Long-life LEDs rated to 100,000 hours of reliable operation
Warranty:
5-Year Warranty on All Emergency Vehicle Lighting Products*
Included in Box:
Q4 strobe light
3M adhesive mount
Screws
Owner's Manual
Dimensions:
57 x 45 x 11mm
Interchangeable/Compatible with:
All automobiles and devices are equipped with a 12 or 24-volt DC power source.
